Road Stream Crossing Site UBR_MC03
Upper Black River Watershed, Gokee Creek
Walker Rd
Walker Twp,
Cheboygan County
Information collected by:
Site Location
GPS Coordinates: 45.34304
, -84.39387
T34N
R1W
Sec 11, 14
Owned by Private
Fish Passability 0.5
Structure is NOT Perched
Total Erosion: 5.2833 tons/year
Severity: Severe
Year Inventoried: 2015
Site ID
Inlet
Outlet
Upstream Conditions
Downstream Conditions
Road Approach - Right
Road Approach - Left
Crossing Information
Type of Crossing: culvert(s)
Number of Structures: 1
Structure Shape: Round
Inlet Type: Wingwall 10-30 Degree
Outlet Type: At Stream Grade
Structure Material: Metal
Structure Substrate: None
General Conditions: Good
Structure Interior: corrugated
Dimensions of Structure: Length 80 ft.
, Width 6 ft.
, Height 4.7 ft.
Structure is NOT Perched
Structure Inlet
Water Depth: 0.3 ft.
Embedded Depth of Structure: 0 ft.
Water Velocity*: 0.2 ft./sec.
Structure Outlet
Water Depth: 0.7 ft.
Embedded Depth of Structure: 0 ft.
Water Velocity*: 0.1 ft./sec.
*Water Velocities were measured at the Surface
(with Meter)
Stream Information
Stream Flow: Less than Bankfull
Scour Pool: Length 0 ft.
, Width 0 ft.
, Depth 0 ft.
Upstream Pond: Length 0 ft.
, Width 0 ft.
, Depth 0 ft.
Riffle Information
Water Depth: 1 ft.
Bankfull Width: 8 ft.
Wetted Width: 4 ft.
Water Velocity: 0.1 ft./sec.
(Measured with Meter)
Dominant Substrate: Gravel
Road Information
Gravel
County Road
Road Condition: Good
Road Width at Culvert: 27.6 ft.
Location of Low Point: At Stream
Runoff Path: Ditch
Embankments
Upstream
Fill Depth: 1.5 ft.
Slope: More than 1:2
Downstream
Fill Depth: 2 ft.
Slope: More than 1:2
Approaches
Left Approach
Length: 277 ft.
Slope: 1% to 5%
Vegetation: Heavy
LS Factor: 0.451
Erosion: 0.9494 tons/year
Right Approach
Length: 1000 ft.
Slope: 1% to 5%
Vegetation: Heavy
LS Factor: 0.57
Erosion: 4.3339 tons/year
Erosion Information
Total Erosion at Crossing: 5.2833 tons/year
Summary Information
Fish Passability 0.5
