Road Stream Crossing Site S701
Boardman River Watershed, Kids Creek Tributary B
Orange Drive
Crossing: Orange Drive / Kids Creek Tributary B
Garfield Twp,
Grand Traverse County
Information collected by:
GPS Coordinates: 44.75067
, -85.64655
T27N
R11W
Sec 9
Adjacent Land Owned by Local Government
Severity: Moderate
Site Location
Crossing Information
Road Width at Culvert: 17.5 ft.
Road Surface: Gravel
Maintenance: seasonal
Low Point: At paved parking lot north of crossing
Existing Drainage Control? no
Any Failings? no
Type of Crossing: culvert(s)
(single culvert)
Is this crossing constricted? no
Are there adjacent wetlands? yes
Comments: This site has three seperate culverts... see notes at bottom of page
Approaches
Left Approach
Length: 47 ft.
Slope: 0%
Vegetation: heavy
Right Approach
Length: 706 ft.
Slope: 1-5%
Vegetation: heavy
Culvert Information
Embankments
Upstream
Embankment Slope: 1:1 slope
Downstream
Embankment Slope: 1:1 slope
Stream Information
Upstream
Stream Width: 3 ft.
Stream Depth: 3 in.
Stream Current: moderate
Stream Substrate: sand
Downstream
Stream Width: 3 ft.
Stream Depth: 3 in.
Stream Current: moderate
Stream Substrate: sand
Erosion Information
Conditions
Is there Streambank erosion beside the crossing? no
Is there embankment erosion? yes
Is there erosion at the culvert outlet? no
Is there erosion at the shoulder and/or ditch? yes
Is there pooling at the outlet? no
Is there sand over the crossing? no
Extent of Erosion: moderate
Cause of Erosion: road runoff at culvert #3
Recommended Treatments
Action Recommended? yes
Add pavement? yes
Pave Left Approach: 47 Lineal Feet
Pave Right Approach: 706 Lineal Feet
Add paved raised edge? no
Increase fill? no
Replace culvert(s)? no
Extend culvert(s)? no
Comments: Culvert #1: Galvanized at one end, concrete at the other, good condition, clear flow, round, 2.5 ft diameter.
Culvert #2: Galvinized, fair condition, 75% obstructed, 2.5 ft diameter.
Culvert #3: Galvanized, clear flow, perched 12", 1 ft diam
Culvert #2: Galvinized, fair condition, 75% obstructed, 2.5 ft diameter.
Culvert #3: Galvanized, clear flow, perched 12", 1 ft diam
Severity:Moderate
