Road Stream Crossing Site PLT-H-47

Platte River Watershed, Collision Creek
Valley Rd
Homestead Twp, Benzie County
Information collected by:
GPS Coordinates: 44.6634 , -86.00178
T26 R14 Sec 10
Adjacent Land Owned by Private
Severity: Moderate
Cost: $0.00
Site Location

Inlet
Outlet
Upstream Conditions
Downstream Conditions
Road Approach - Left
Road Approach - Right
Crossing Information
Road Width at Culvert: 25 ft.
Road Surface: Paved
Maintenance: year around
Low Point: At Stream
Existing Drainage Control? no
Any Failings? no
Type of Crossing: culvert(s) (single culvert)
Is this crossing constricted? no
Are there adjacent wetlands? yes
Comments: Culvert is positioned under west driveway. The outlet is perched by 0.8 feet. Aprons have been adde
Approaches
Left Approach
Length: 100 ft.
Slope: 0%
Vegetation: partial
Right Approach
Length: 150 ft.
Slope: 0%
Vegetation: partial
Culvert Information
Length: 18 ft.
Diameter: 2.5 ft.
Material: galvanized
Condition :good
Flow: clear
Embankments
Upstream
Fill Depth: 3 ft.
Embankment Slope: vertical
Downstream
Fill Depth: 3 ft.
Embankment Slope: vertical
Stream Information
Upstream
Stream Width: 3 ft.
Stream Depth: 0.5 in.
Stream Current: slow
Stream Substrate: sand
Downstream
Stream Width: 3 ft.
Stream Depth: 0.5 in.
Stream Current: slow
Stream Substrate: sand
Erosion Information
Conditions
Is there Streambank erosion beside the crossing? no
Is there embankment erosion? no
Is there erosion at the culvert outlet? no
Is there erosion at the shoulder and/or ditch? no
Is there pooling at the outlet? no
Is there sand over the crossing? no
Other Conditions: Road Commission had noted sheet flow down Valley Road during larger flow events

Extent of Erosion: moderate
Recommended Treatments
Action Recommended? no
Add pavement? no
Pave Left Approach: 0 Lineal Feet
Pave Right Approach: 0 Lineal Feet
Add paved raised edge? no
Number of erosion control structures: 0
Number of sediment basins: 0
Number of diversion outlets: 0
Increase fill? no
Replace culvert(s)? yes
Extend culvert(s)? no
Lineal feet to extend: 0
Other Treatments: All inclusive hydrologic plan for Valley Road.
Comments: Collision Creek utilizes 36 culverts to transverse Valley Road. All Collision Creek culverts should be dealt with as one (potentially multi phase) project. Cost estimate yet to be determined.

Total Points:0
Severity:Moderate
