Road Stream Crossing Site B-102

Betsie River Watershed, Betsie Lake tributary
M-22
Crystal Lake Twp, Benzie County
Information collected by:
GPS Coordinates: 44.62586977 , -86.22063652
T26N R16W Sec 26
Adjacent Land Owned by Private
Severity: Minor
Cost: $0.00
Site Location

Inlet
Outlet
Road Approach - Left
Road Approach - Right
Crossing Information
Road Width at Culvert: 36 ft.
Road Surface: Paved
Maintenance: year around
Low Point: Other
Existing Drainage Control? no
Any Failings? no
Type of Crossing: culvert(s) (single culvert)
Is this crossing constricted? no
Are there adjacent wetlands? yes
Approaches
Left Approach
Length: 0 ft.
Slope: 0%
Vegetation: partial
Right Approach
Length: 0 ft.
Slope: 0%
Vegetation: partial
Culvert Information
Length: 50 ft.
Diameter: 48 ft.
Material: concrete
Condition :good
Flow: fish passage problem
Embankments
Upstream
Fill Depth: 7 ft.
Embankment Slope: 2:1
Downstream
Fill Depth: 7 ft.
Embankment Slope: 2:1
Stream Information
Upstream
Stream Width: 2 ft.
Stream Depth: 0.5 in.
Stream Current: moderate
Stream Substrate: sand
Downstream
Stream Width: 3 ft.
Stream Depth: 0.5 in.
Stream Current: moderate
Stream Substrate: muck
Erosion Information
Conditions
Is there Streambank erosion beside the crossing? no
Is there embankment erosion? no
Is there erosion at the culvert outlet? no
Is there erosion at the shoulder and/or ditch? no
Is there pooling at the outlet? no
Is there sand over the crossing? no

Extent of Erosion: minor
Recommended Treatments
Action Recommended? yes
Add pavement? no
Add paved raised edge? no
Number of erosion control structures: 0
Number of sediment basins: 0
Number of diversion outlets: 0
Increase fill? no
Replace culvert(s)? no
Dimensions of replacement: 0
Extend culvert(s)? no
Lineal feet to extend: 0

Severity:Minor
