Road Stream Crossing Site P085

Pine River Watershed, Tributary to Pine River
230th Ave
Burdell Twp, Osceola County
Information collected by:
GPS Coordinates: 44.09614 , -85.54327739
T20N R10W Sec 30
Adjacent Land Owned by Private
Severity: Moderate
Cost: $35,800.00
Site Location

Inlet
Outlet
Road Approach - Left
Road Approach - Right
Crossing Information
Road Width at Culvert: 22 ft.
Road Surface: Sand
Gravel
Maintenance: year around
Low Point: At Stream
Existing Drainage Control? no
Any Failings? no
Type of Crossing: culvert(s) (single culvert)
Is this crossing constricted? no
Are there adjacent wetlands? no
Approaches
Left Approach
Length: 550 ft.
Slope: 6-10%
Vegetation: partial
Right Approach
Length: 400 ft.
Slope: 6-10%
Vegetation: partial
Culvert Information
Length: 75 ft.
Diameter: 36 ft.
Material: galvanized
Condition :fair
Flow: clear
Embankments
Upstream
Fill Depth: 10 ft.
Embankment Slope: 1:1
Downstream
Fill Depth: 10 ft.
Embankment Slope: 1.5:1
Stream Information
Upstream
Stream Width: 0.5 ft.
Stream Depth: 0.5 in.
Stream Current: slow
Stream Substrate: muck
Downstream
Stream Width: 1 ft.
Stream Depth: 0.5 in.
Stream Current: slow
Stream Substrate: muck
Erosion Information
Conditions
Is there Streambank erosion beside the crossing? no
Is there embankment erosion? no
Is there erosion at the culvert outlet? no
Is there erosion at the shoulder and/or ditch? yes
Is there pooling at the outlet? no
Is there sand over the crossing? no

Extent of Erosion: minor
Cause of Erosion: road runoff
Recommended Treatments
Action Recommended? no
Add pavement? yes
Add paved raised edge? yes
Number of erosion control structures: 0
Number of sediment basins: 0
Number of diversion outlets: 0
Increase fill? no
Replace culvert(s)? no
Dimensions of replacement: 0
Extend culvert(s)? no
Lineal feet to extend: 0

Severity:Moderate
