Road Stream Crossing Site S910
Boardman River Watershed, Miller Creek Tributary
Private Drive
Garfield Twp,
Grand Traverse County
Information collected by:
GPS Coordinates: 44.71908
, -85.62601
T27N
R11W
Sec 22
Adjacent Land Owned by Private
Severity: Severe
Site Location
Crossing Information
Road Width at Culvert: 40 ft.
Road Surface: Sand
Gravel
Gravel
Existing Drainage Control? no
Any Failings? no
Type of Crossing: culvert(s)
(single culvert)
Is this crossing constricted? yes
Are there adjacent wetlands? yes
Approaches
Left Approach
Slope: 0%
Vegetation: partial
Right Approach
Slope: 1-5%
Vegetation: partial
Culvert Information
Shape: round
Length: 60 ft.
Diameter: 1.5 ft diameter ft.
Flow: obstructed
Embankments
Upstream
Fill Depth: 4 ft.
Embankment Slope: 1:1 slope
Downstream
Fill Depth: 4 ft.
Embankment Slope: 1:1 slope
Stream Information
Upstream
Stream Width: 5 ft.
Stream Depth: 3 in.
Stream Current: slow
Stream Substrate: sand,gravel
Downstream
Stream Width: 3 ft.
Stream Depth: 2 in.
Stream Current: moderate
Stream Substrate: gravel
Erosion Information
Conditions
Is there Streambank erosion beside the crossing? yes
Is there embankment erosion? yes
Is there erosion at the culvert outlet? no
Is there erosion at the shoulder and/or ditch? yes
Is there pooling at the outlet? no
Is there sand over the crossing? yes
Extent of Erosion: severe
Cause of Erosion: Utility clearing, road runoff
Recommended Treatments
Action Recommended? yes
Add pavement? yes
Add paved raised edge? no
Increase fill? no
Replace culvert(s)? no
Dimensions of replacement: round, galvanized, 2 ft diameter, 70 feet long
Extend culvert(s)? no
Other Treatments: Rock rip rap, revegetation
Comments: Culvert Material / Condition:
Inlet - concrete, poor
Outlet - galvanized (extension), good
Replace culvert, pave driveway, then stabilize embankments and stream banks with rock rip rap, seed and mulch, and plantings, etc.
Inlet - concrete, poor
Outlet - galvanized (extension), good
Replace culvert, pave driveway, then stabilize embankments and stream banks with rock rip rap, seed and mulch, and plantings, etc.
Severity:Severe
